Émonda SL 6 Disc has all the advantages of an ultralight carbon road bike, with the added benefit of aero tube shaping that will make you faster on flats and up climbs, too. A performance drivetrain and front and rear thru axles make it a great choice for fast roadies who want the extra confidence of disc brakes that perform in any conditions.
*spec applies to all sizes unless otherwise noted
FRAMESET
|
Frame |
Ultralight 500 Series OCLV Carbon, Ride Tuned performance tube optimization, tapered head tube, internal routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle |
|
Fork |
Émonda SL full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm thru axle |
|
Frame fit |
H1.5 Race |
WHEELS
|
Wheel front |
Bontrager Paradigm Disc, Tubeless Ready, 20mm rim width, 100x12mm thru axle |
|
Wheel rear |
Bontrager Paradigm Disc, Tubeless Ready, 20mm width, Shimano 11/12-speed freehub, 142x12mm thru axle |
|
Hub front |
Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, 100x12mm thru axle |
|
Skewer front |
Bontrager Switch thru axle, removable lever |
|
Hub rear |
Bontrager Affinity Comp, Shimano 11/12 speed freehub, 142x12mm thru axle |
|
Skewer rear |
Bontrager Switch thru axle, removable lever |
|
Rim |
Bontrager Paradigm Comp, Tubeless Ready, 24-hole, 21mm width, presta valve |
|
Tire |
Bontrager R2 Hard-Case Lite, aramid bead, 60 tpi, 700x28c |
|
Max tire size |
30c |
DRIVETRAIN
|
*Shifter |
Size: 47, 50, 52 |
|
Size: 54, 56, 58, 60, 62 |
|
|
Front derailleur |
Shimano Ultegra R8000, braze-on |
|
Rear derailleur |
Shimano Ultegra R8000, short cage, 30T max cog |
|
*Crank |
Size: 47 |
|
Size: 50, 52 |
|
|
Size: 54, 56, 58 |
|
|
Size: 60, 62 |
|
|
Bottom bracket |
Praxis, T47 threaded, internal bearing |
|
Cassette |
Shimano Ultegra R8000, 11-30, 11 speed |
|
Chain |
Shimano Ultegra HG701, 11-speed |
|
Max chainring size |
1x: 50T, 2x: 53/39T |
COMPONENTS
|
Saddle |
Bontrager Aeolus Comp, steel rails, 145mm width |
|
*Seatpost |
Size: 47, 50, 52, 54 |
|
Size: 56, 58, 60, 62 |
|
|
*Handlebar |
Size: 47, 50 |
|
Size: 52 |
|
|
Size: 54, 56, 58 |
|
|
Size: 60, 62 |
|
|
Handlebar tape |
Bontrager Supertack Perf tape |
|
*Stem |
Size: 47 |
|
Size: 50 |
|
|
Size: 52, 54 |
|
|
Size: 56 |
|
|
Size: 58, 60, 62 |
|
|
Brake |
Shimano Ultegra hydraulic disc, flat mount |
|
Brake rotor |
Shimano RT800, centerlock, 160mm |
WEIGHT
|
Weight |
56 - 8.25 kg / 18.18 lbs |
|
Weight limit |
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg). |
**Trek Bikes reserves the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing.
**Weights are based off pre-production products at time of publication. Weights may vary in final production.
|
Size |
Rider Height |
Inseam |
|
44 |
150 - 153 cm 4'11" - 5'0" |
71 - 73 cm 28" - 29" |
|
49 |
156 - 163 cm 5'1" - 5'4" |
74 - 77 cm 29" - 30" |
|
52 |
163 - 168 cm 5'4" - 5'6" |
76 - 79 cm 30" - 31" |
|
54 |
168 - 174 cm 5'6" - 5'9" |
78 - 82 cm 31" - 32" |
|
56 |
174 - 180 cm 5'9" - 5'11" |
81 - 85 cm 32" - 33" |
|
58 |
180 - 185 cm 5'11" - 6'1" |
84 - 87 cm 33" - 34" |
|
61 |
185 - 191 cm 6'1" - 6'3" |
86 - 90 cm 34" - 35" |
