Procaliber 9.5 is a lightweight carbon hardtail with the unique advantage of our trail-smoothing IsoSpeed decoupler. It's the most affordable carbon model in the Procaliber mountain bike family, and it's built for speed and efficiency on singletrack with a wide-range Shimano Deore 1x12 drive train, RockShox Judy SL fork and speedy 29er wheels.
*spec applies to all sizes unless otherwise noted**Trek Bikes reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing.
**Weights are based off pre-production products at time of publication. Weights may vary in final production.
FRAMESET
| Frame | OCLV Mountain Carbon, IsoSpeed, tapered head tube, Knock Block, internal control routing, balanced post-mount brake, Boost148 |
|---|---|
| Fork | RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, Boost110, 15 mm Maxle Stealth, 100 mm travel |
| Max compatible fork travel | 120mm (533 axle-to-crown) |
COMPONENTS
| Saddle | Bontrager Arvada, steel rails, 138 mm width |
|---|---|
| *Seatpost | Size: S Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length |
| Size: M Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length |
|
| Size: M/L, L, XL, XXL Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length |
|
| *Handlebar | Size: S, M, M/L Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width |
| Size: L, XL Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750 mm width |
|
| Size: XXL Bontrager Line, alloy, 35 mm, 15 mm rise, 750 mm width |
|
| Grips | Bontrager XR Trail Comp, nylon lock-on |
| *Stem | Size: S Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree, 60 mm length |
| Size: S Bontrager Rhythm Comp, Knock Block, 31.8 mm, 0-degree, 60 mm length |
|
| Size: M, M/L Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0-degree, 70 mm length |
|
| Size: M, M/L Bontrager Rhythm Comp, Knock Block, 31.8 mm, 0-degree, 70 mm length |
|
| Size: L, XL Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree, 80 mm length |
|
| Size: L, XL Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0-degree, 80 mm length |
|
| Size: XXL Bontrager Elite, 35 mm, 0-degree, 90 mm length |
|
| Size: XXL Bontrager Kovee Pro, 35 mm, Knock Block, Blendr-compatible, 13-degree, 90 mm length |
|
| Head set | Knock Block Integrated, 62-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom |
| Brake | Shimano MT200 hydraulic disc |
| *Brake rotor | Size: S, M, M/L, L, XL, XXL Shimano RT26, 6-bolt,160 mm |
| Size: L, XL, XXL Shimano RT26, 6-bolt,180 mm |
WEIGHT
| Weight | M - 11.64 kg / 25.67 lbs (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
DRIVETRAIN
| Shifter | Shimano Deore M6100, 12-speed |
|---|---|
| Rear derailleur | Shimano Deore M6100, long cage |
| *Crank | Size: S, M Shimano MT511, 30T steel ring, 52 mm chainline, 170 mm length |
| Size: M, M/L, L, XL, XXL Shimano MT511, 30T steel ring, 52 mm chainline, 175 mm length |
|
| Bottom bracket | Shimano MT500, 92 mm, PressFit |
| Cassette | Shimano Deore M6100, 10-51, 12-speed |
| Chain | Shimano Deore M6100, 12-speed |
| Max. chainring size | 36T, Min 30T |
WHEELS
| Wheel front | Bontrager Kovee TLR rim/DC-611 Boost hub, 29'', 28H, 15 Gauge Spokes, Black/Black |
|---|---|
| Wheel rear | Bontrager Kovee TLR rim/MST148A Boost hub, 29'', 28H, 15 Gauge Spokes, Micro Spline Freehub, Black rim graphics, spokes, and nipples |
| Hub front | Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle |
| Hub rear | Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle |
| Skewer rear | Bontrager Switch thru-axle, removable lever |
| Rim | Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve |
| Spokes | 15 g stainless steel |
| Tyre | Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.20" |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Rim strip | Bontrager TLR |
| Max tyre size | Frame: 29x2.40" Fork: See manufacturer |
|
Size |
Rider Height |
Inseam |
|
XS |
145 - 155 cm 4'9" - 5'1" |
69 - 73 cm 27" - 29" |
|
S |
155 - 165 cm 5'1" - 5'5" |
74 - 78 cm 29" - 31" |
|
M |
165 - 176 cm 5'5" - 5'9" |
79 - 83 cm 31" - 33" |
|
M/L |
173 - 180 cm 5'8" - 5'11" |
81 - 86 cm 32" - 34" |
|
L |
177 - 188 cm 5'10" - 6'2" |
84 - 89 cm 33" - 35" |
|
XL |
188 - 195 cm 6'2" - 6'5" |
89 - 91 cm 35" - 36" |
|
2XL |
195 - 203 cm 6'5" - 6'8" |
91 - 97 cm 36" - 38" |
