The Dual Sport 3 is a high-performance, go-anywhere hybrid bike that transitions from road to rougher terrain with ease. It has a light frame and a low-maintenance 1x drivetrain with a wide range of gears. Its wide Bontrager Kovee wheels and lofty gravel tyres soak up bumps and rough terrain for a comfortable, confident ride on road, rail trails and light dirt paths.
You're looking for a light, fast, and capable hybrid bike with quality parts. You plan to use your bike to explore light trails, hit the pavement for fast fitness rides, run errands, and more.
A lightweight aluminum frame with sleek internal cable routing, a lightweight carbon fork, wide tubeless ready Bontrager Kovee 650b wheels and wide 50c tires for capability and comfort on varied terrain, and a simple 1x10 Shimano Deore drivetrain that ditches the front derailleur for easier operation. Don't worry, the wide-range 11-46 cassette still gives you all the gears you need to conquer hills and crush flats. Plus, powerful disc brakes and mounts for a rack and fenders.
Dual Sport 3 is fast and efficient on pavement and confident and capable on dirt and gravel trails. It has terrain-smoothing wheels and tires and a sturdy and simple 1x Shimano drivetrain.
*spec applies to all sizes unless otherwise noted
FRAMESET
|
Frame |
Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5 mm QR |
|
Fork |
Dual Sport Carbon, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm QR |
|
Hub front |
Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
|
Skewer front |
139x5 mm bolt-on |
|
Hub rear |
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
|
Skewer rear |
152x5 mm QR |
|
Rim |
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve |
|
Tyre |
Bontrager GR0 Expert, wire bead, puncture protection, 60 tpi, 650x50 mm |
|
Max tyre size |
27.5x2.00" |
DRIVETRAIN
|
Shifter |
Shimano Deore M4100, 10-speed |
|
Rear derailleur |
Shimano Deore M5120, long cage |
|
*Crank |
Size: S, M |
|
Size: L, XL |
|
|
Cassette |
Shimano Deore M4100, 11-46, 10-speed |
|
Chain |
KMC X10, 10-speed |
|
Pedal |
Wellgo nylon body, alloy cage |
|
Max. chainring size |
1x: 42T, 2x/3x: 48T |
COMPONENTS
|
Saddle |
Bontrager H1 |
|
Seatpost |
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length |
|
*Handlebar |
Size: S |
|
Size: M, L |
|
|
Size: XL |
|
|
Grips |
Bontrager XR Endurance Elite |
|
*Stem |
Size: S |
|
Size: M, L |
|
|
Size: XL |
|
|
Brake |
Shimano hydraulic disc, MT201 lever, UR300 calliper |
|
Brake rotor |
Shimano RT26, 6-bolt,160 mm |
|
Rotor size |
Max brake rotor sizes: 160mm front & rear |
|
Weight |
M - 11.88 kg / 26.2 lbs |
|
Weight limit |
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
**Trek Bikes reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing.
**Weights are based off pre-production products at time of publication. Weights may vary in final production.
| Size | Rider Height | Inseam |
|---|---|---|
| XS |
147 - 155 cm 4'10" - 5'1" |
69 - 73 cm 27" - 29" |
| S |
155 - 165 cm 5'1" - 5'5" |
72 - 78 cm 28" - 31" |
| M |
165 - 175 cm 5'5" - 5'9" |
77 - 83 cm 30" - 33" |
| L |
175 - 186 cm 5'9" - 6'1" |
82 - 88 cm 32" - 35" |
| XL |
186 - 197 cm 6'1" - 6'6" |
87 - 93 cm 34" - 37" |
